کتاب ارتباطات گرافیکی فنی ، چاپ 4

Bertoline places a strong emphasis on design and industrial applications. Examples are found throughout the text, reinforcing the real and practical ways that technical graphics skills are used in real companies. This text presents both traditional and modern approaches to technical graphics, providing engineering and technology students with a strong foundation in standard drafting practices and techniques.

Sample questions asked in the 4th edition of Technical Graphics Communcatns:

When the size of a hexagon is specified ‘across the flats’, the hexagon is constructed by inscribing it in a circle.

In a two-point perspective drawing, the vanishing points are located on the: a. ground line b. horizon line c. measuring line d. station point

Which two methods of defining a workplane both define the workplane parallel to a planar face? a. Tangent and Through b. Offset and Tangent c. Angle and Orientation d. Through and Offset
